Page 7
Gallagher T20 Reader
Installaon Note
Document Code: 3E3140
Edion 3, April 2013
Gallagher Reader Module 8R or 4R (aached to the Controller 6000)
Connect the wires to the sockets as shown:
- + R1 Out R1 In C 1 2
3 C 4 5
6
R2 Out R2 In
Gallagher Reader Module
Negave Black
Posive Red
Reserved Orange
Reserved Green
Reserved Brown
CDXIV RX Blue
CDXIV TX White
Cardax IV Reader 1
Negave Black
Posive Red
Reserved Orange
Reserved Green
Reserved Brown
CDXIV RX Blue
CDXIV TX White
Cardax IV Reader 2
Gallagher GBUS Universal Reader Interface (Gallagher GBUS URI)
Connect the wires to the sockets as shown in either of the following diagrams:
RLY 2 COM RLY 2 NO RLY 2 NC DATA 0 DATA 1 OUT 1 OUT 2 COM A COM B TAMPER GND VOUT GND VIN GND
Pin 15
Reader
Top Row
Pin 1
Gallagher GBUS URI
Posive Red Negave Black Reserved Orange Reserved Green Reserved Brown CDXIV TX White CDXIV RX Blue
Cardax IV Reader
RLY 2 COM RLY 2 NO RLY 2 NC DATA 0 DATA 1 OUT 1 OUT 2 COM A COM B TAMPER GND VOUT GND VIN GND
Pin 15
Reader
Top Row
Pin 1
Gallagher GBUS URI
Posive Red Negave Black Reserved Orange Reserved Green Reserved Brown CDXIV TX White CDXIV RX Blue
Cardax IV Reader
