ANNEX K:
To install the E-heating tape at the drainage outlet (by client)
Connect the wireCeating tape at the drainage outlet to the wire joint XT3.
XT3
To the heating
tape of drainage
outlet
L N
L N
4/6kW
XT3
To the heating
tape of drainage
outlet
8/10kW
L N
L N
