The picture is for reference only,please refer to the actual product.
The power of the E-heating tape shall not exceed 40W/200mA, supply volatge 230VAC.
NOTE:
XT3
To the heating
tape of drainage
outlet
12/14/16kW(1-phase)
XT3
To the heating
tape of drainage
outlet
12/14/16kW(3-phase)
ANNEX K:
L N
L N
L N
L N
