9. APPENDIX: EXPLODED PARTS DIAGRAM
Key Part Name Qty
1 Main Unit with Legs 1
2 1¼”-1 ½” Hose Reducer 2
3 Collar 2
4 Hose Clamp 2
5 Flat Gasket 2
6 Hose Adapter with O-Ring 2
7 Filter Hose 2
8 Adapter with O-Ring for INTEX® Pools 2
~ OR ~
Adapter with O-Ring for BESTWAY® Pools 2
Note: Some parts may be pre-installed at the factory.
Parts not shown to scale.
Main Unit
with Legs (1)
Collar (2)
Hose Adapter with
O-Ring (2)
Adapter with O-Ring
for INTEX® Pools (2)
Adapter with O-Ring
for BESTWAY® Pools (2)
1¼”-1 ½” Hose
Reducer (2)
Hose Clamp (2)
~ OR ~
Filter Hose (2)
Flat Gasket (2)
