Supported fans (maximum)
Front: 2x 120mm
Back: 1x 120mm
For superior performance, the chassis allows the use of
a CPU cooler (135mm maximum Height)
Support 2.5” SSD x2
I/O PANEL
PIN diagram for I/O panel cable
Power
Reset
HD AudioUSB 3.0
USB 2.0
USB 3.0 CONNECTOR USB 2.0 CONNECTOR HD AUDIO CONNECTOR
Support 3.5” HDD x2
Remove the PCI slot protection cover.
Install the graphics card and secure it with
a screw.
