Supported fans (maximum)
Front: 2x 120 mm(optional)
Back: 1x 120 mm(included)
For superior performance, the chassis allows the use of
a CPU cooler (135mm maximum Height)
I/O PANEL
PIN diagram for I/O panel cable
Power
Reset
HD Audio
USB 2.0
USB 3.0
Remove the PCI slot protection cover.
Install the graphics card and secure it with
a screw.
USB 3.0 CONNECTOR USB 2.0 CONNECTOR HD AUDIO CONNECTOR
INSTALL 2.5” SSD
INSTALL 3.5” HDD POSITION 1 INSTALL 3.5” HDD POSITION 2
INSTALL THE FANS INSTALL THE GRAPHICS CARD (VGA)
