BUTTON REPLACEMENT
a. Take out the hex screw driver from the storage space at the back of the GameSir C2 arcade
fightstick.
b. Unscrew the 7 screws at the bottom of GameSir C2 arcade fightstick and remove the base plate.
c. Disconnect the cable from the button you would like to replace. Press the plastic tabs on each
side of the button to remove the button from the top panel.
d. Install the new button from the top panel and rotate the button until you hear a click sound. The
button is now locked in the top panel.
e. Reconnect the correct color cable to the button according to the following cable assignment label.
Yellow
Orange
LB
LT
RB
RT
Y
B
X
A
Blue Black Purple
Green Red Brown
