Preparing the transfer stand: The attachment
screws of the two axes (brass elements) must
be loosened, so that the axis springs push them
completely to the ends. The bars of the built-in
bite fork support must be moved completely to
the bottom. The height setting of the upper sec-
tion is turned to the top.
After removing the glabella support, insert the
face bow with the axis pin into the bore of the
open axis and move it towards the center, until
it is possible to hook in the fixed axis of the other
side.
The second axis can now be locked. The two
axes must be positioned in equidistance.
The face-bow is now resting on the bite fork
joint, propped up on the white pedestal. Care-
fully move the bars of the bite fork support up-
wards to the bite fork, for further stability.
