Centering the model in the articulator:
The slide on the distance ruler must be moved
completely to the end, and then fixed.
Insert the ruler on one side by attaching the slot
of the ruler onto the corresponding needle of the
axis indicator holder.
Now you can read the distance to the other side
on the 2 mm scale of the ruler.
