Reference SL Articulator and Face Bow Systems
To adjust the angle, first loosen the condylar
housing fixing screw. Set the desired value on
the scale, then tighten the screw again.
Fixing and adjusting the TCI insert:
Simply pull out the old insert from the groove
and slide in the new insert.
To set the angle, loosen the TCI attaching
screw on the condylar housing back panel. Set
the value on the scale, then tighten the screw
again.
