Instruction Manual
-
12
-
Gently push the porus supports in
to t
he ear ca-
nals.
Stretch the forehead
skin.
Push
the
glabella
support
carefully
and
without
pressure
onto
the
nasio
n
and
tighten
t
he
Gla-
bella support screw
.
Optionally
,
to
improve
the
stability
of
the
face
bow
further, you can
attach the reten
t
ion straps
junior
(01-SP0040-J)
.
Stretch
them
equally
on
both
sides
and
close
them
at
the
back
of
the
head with the hoo
k-
and
-loop fastener
.
