7 Curve of Spee Analyzer Set
The curve of Spee analyzer serves for analyz-
ing the sagittal compensation curve in the area
of the posterior teeth of the model. The tem-
plates may not directly be used for patients. The
application is for the Reference SL articulator
only.
The set (art. no. 04-000019) includes 7 tem-
plates with radii from 60 to 90 mm in steps of 5
mm and an axial support pin for the Reference
SL articulator.
(The shown pedestal is not included in the set.
It can be ordered as a special spare part.)
Preparation:
Firstly, separate the upper and the lower section
of the Reference SL articulator. Remove the in-
cisal pin unit.
