The Reference AB face-bow can now be re-
moved from the articulator.
5.3.2 Using the Reference AB junior face bow
For directly transferring the upper jaw model us-
ing transfer stand AB2 junior (06-231400-J) or
for indirectly transferring the position of the bite
fork using transfer stand AB junior (06-216280-
J), please refer to the actual version of the re-
spective manual.
5.4 Transferring the upper jaw model according to the kinematic axis
5.4.1 Using Condylograph comfort Set or Condylograph comfort Set I
Mounting the upper jaw model in the Reference
SL articulator, according to the kinematic (ex-
act) hinge axis and individual reference plane,
is carried out using the Condylograph comfort
Set (04-GCR311) or the Condylograph comfort
Set I (04-GCR311I).
