Move the O-rings of the articulator axes into a
slightly medium position. (see adjoining pic-
ture!)
Insert and fix the articulator axes in the adjust-
ment blocks:
a) Insert the axes into the bore of the adjust-
ment blocks.
b) Apply counter pressure with the other hand
(see adjoining picture!)
c) Axis has to be in precise contact with the TCI
insert.
