20
PARTS LIST
6B CAP SCREW- M8x30
104 TENSIONER ASSEMBLY
105 RETAINER SCREW
112 TOOL TRAY
113 LONG LEG
114 SHORT LEG
115 FLAT HEAD SCREW- M8x25
116A LOWER COLUMN SUPPORT
119 BELLOWS
120A UPPER COLUMN SUPPORT
121 LEVELING FOOT
165 SET SCREW- M8x10
203 TT SCREWS*
283 TT END CAP
285 TT END CAP- RIGHT
286 TT END CAP- LEFT
289 TT HANDLES
304 SC TT KNOB
309 2 PT PAD
310 2 PT HOLD DOWN
311 2 PT RQT SUPPORTS
312 2 PT LEVER
313 2 PT MOUNTING STAND
314 2 PT MOUNTING ASSY
315 2 PT GRABBER PLATE
320 BRAKE RING
327 TT PIN
336 WINDER BAR
337 BRAKE BOX
362 SC TURNTABLE TT9
389 2PT TOP CAP w/ADJ SCREW
390 2 PT STICKER
MDCSC13 UNIV DIECAST STRING CLAMP
MQAC12 QA BASE CLAMP TT7/TT8/TT9
98 10MM WRENCH*
109 NEEDLE NOSE PLIERS*
110 BENT NOSE PLIERS*
171 DIAGONAL CUTTERS*
196 17MM SOCKET*
251 HEX WRENCH SET*
MA STRINGER’S AWL*
MPSA PATHFINDER AWL*
* (NOT SHOWN)
OPTIONAL TOOLS & ACCESS
PART # DESCRIPTION TOOLS & ACCESSORIES
MFSC FLOOR STAND CASTERS
MGSMC MACHINE COVER
MPG STARTING CLAMP
MPS CLEANING STONE
MTC CALIBRATOR
SGSM STRINGER’S MAT
