28
PARTS LIST
6B CAP SCREW - M8x30
14 WASHER- M10
106 STAND BRAKE KNOB
114 SHORT LEG
115 FLAT HEAD SCREW- M8x25
121 LEVELING FOOT
144 SHLDER SUPP LOCK KNOB
203 TT SCREWS*
210 STRING REEL HOLDER BOLT
211 STRING REEL HOLDER SPACER
212 STRING REEL HOLDER KNOB
259 SLIDE BRACKET
265 LEFT DRAWER END CAP
270 SUPP POST MOUNT PLATE
276 RIGHT DRAWER END CAP
277 BASE CORNER CAP
278 BASE CORNER CAP
283 END CAP
285 TT END CAP- RIGHT
286 TT END CAP- LEFT
287 BASE END CAP (R)
288 BASE END CAP (L)
289 TT HANDLES
292 BASE
293 TOOL TRAY
295 TOOL TRAY PAD
297 LOWER COLUMN
298 UPPER COLUMN
299 STRING LENGTH METER
301 RUBBER FOOT
320 BRAKE RING
321 BRAKE BOX (ELS)
322 LARGE DRAWER
323 SMALL DRAWER
324 FOOT PEDAL SWITCH*
327 TT PIN
360 TURNTABLE TT7
364 A220 MNTNG ARM- RIGHT
365 A220 MNTNG ARM- LEFT
366 A220 TOP PLATE
367 A220 TOP PLATE ARM PADS
109 NEEDLE NOSE PLIERS*
110 BENT NOSE PLIERS*
171 DIAGONAL CUTTERS*
196 17MM SOCKET*
221 SLM PADS*
251 HEX WRENCH SET*
MA STRINGER’S AWL*
MFSPP13 FRAME SUPP PAD SET
6 FRAME PADS
2 BAD SLIDE ON “H” PADS
MMSPP13 V-MNT SHOULDER SUPP PAD
MBMSP11 BADM SHOULDER SUPP COVER
MPG STARTING CLAMP*
MPS CLEANING STONE*
MPSA PATHFINDER AWL*
MGEMC MACHINE COVER *
* (NOT SHOWN)
MBFS-14 BADM HEAD FRAME SUPP
MFSC FLOOR STAND CASTERS
MTC CALIBRATOR
SGSM STRINGER’S MAT
MBMSS11 BADM MOUNTING SYS UPG
OPTIONAL TOOLS & ACCESS
PART # DESCRIPTION
TOOLS & ACCESSORIES
368 A220 SUPP ARM KNOB & SCREW
369 A220 FRAME KNOB & SCREW
370 ADJ KNOB RUBBER GRIP
371 A220 SHOULDER V-MNT (BLK)
372 A220 FRAME SUPPORT
382 A220 SC MNTING STAND
395 DIE-CAST LINEAR GRIPPER
396 5800 TENSIONER wLCD
MDCSC13 UNIV DIECAST STRING CLAMP
MQAC12 QA CLAMP BASE TALL TT7/TT8
E16 A/C POWER CORD*
E23 A/C ADAPTER*
E86 LCD KEYPAD/ ELECTRONICS
PART # DESCRIPTION
