DMX Channel Mode Sheet:
On the left side of the sheet you will see the different modes and which channel
corresponds to each function listed on the right in the given mode.
18CH 16CH Function Channel Value Description
1 1 Pan 0-255 0-540°
2 Pan Fine 0-255 Pan Fine
3 2 Tilt 0-255 0-270°
4 Tilt Fine 0-255 Tilt Fine
5 3 Movement
Speed
0-255 Fast to slow
6 4 Intensity 0-255 Dimmer Control
7 5 Strobe 0-7 Strobe off
8-250 Strobe, Slow to Fast
251-255 Strobe off
8 6 Color Wheel 0-15 No Color/White
16-31 Red
32-47 Green
48-63 Yellow
64-79 Deep Blue/Indigo
80-95 Magenta
96-111 Amber
112-127 Cyan
128-191 CW scroll, slow to fast
192-255 CCW scroll, slow to fast
9 7 Color
Indexing
0-10 No Function
11-209 Color Index (Allows for
variable splits between any 2
colors on the wheel)
10 8 Gobo Wheel
1 – Static
0-6 Open
7-13 Gobo 1
