Installation and Operation Instructions
23
Drip
Loop
Figure 14. Fixing clamps to the edge of the roof without gutters.
Figure 15. Fixing the clamps to the roof as the height of the triangle increases.
For triangles that are more than 3-feet high, also attach clips every 3-feet along
the height of the triangle.
