Technical Specifications:
L3:
High frequency driver 38mm (1,5”) ring radiator, SD-2 neodymium motor, non-resonant aluminium chamber, multiple chamber low
compression design, machined aluminum faceplate and stainless steel phase plug
Low/mid frequency driver Two 180mm (7”) bass/midrange, powerful vented SD-1 motor, sliced paper cone, low loss linear suspension,
low compression aerodynamic aluminium chassis, spike-mounted in cabinet
Crossover network Multi order Non-Resonant Linked Impulse (NRLI) technology by GamuT,
Electromagnetic and circuit optimized bi-level board layout
Cabinet High density fiber board featuring internal skeleton braces and dampened with bitumen.
Realwood veneer with eleven layers of hand polished high-gloss lacquer
Frequency response 42 – 60.000Hz
Sensitivity 88dB @ 2,83V
Impedance 6 ohms nominal, minimum 4,6 ohms @ 200Hz
Recommended power 50-300W
Input connections High-quality, gold plated WBT binding posts with 4mm plugs. Bi-wire and bi-amp capability
Cabinet dimensions (HxWxD) 380 x 200 x 380mm (15 x 7.9 x 15”)
Weight 15 kg (34lbs)
L5:
High frequency driver 38mm (1,5”) ring radiator, SD-2 neodymium motor, non-resonant aluminium chamber, multiple chamber low compression
design, machined aluminum faceplate and stainless steel phase plug
Low/mid frequency driver Two 180mm (7”) bass/midrange, powerful vented SD-1 motor, sliced paper cone, low loss linear suspension,
low compression aerodynamic aluminium chassis, spike-mounted in cabinet
Crossover network Multi order Non-Resonant Linked Impulse (NRLI) technology by GamuT,
Electromagnetic and circuit optimized bi-level board layout
Cabinet High density fiber board featuring internal skeleton braces and dampened with bitumen.
Realwood veneer with eleven layers of hand polished high-gloss lacquer
Frequency response 32 – 60.000Hz
Sensitivity 89dB @ 2,83V
Nominal impedance 4 ohms nominal, minimum 2,8 ohms at 200Hz
Recommended power 50-300W
Input connections High-quality, gold plated WBT binding posts with 4mm plugs. Bi-wire and bi-amp capability
Cabinet dimensions (HxWxD) 1150 x 200 x 430mm (45.3 x 7.9 x 16.9”)
Weight 39 kg (88.4lbs)
Stands Stainless steel spikes
L7:
High frequency driver 38mm (1,5”) ring radiator, SD-2 neodymium motor, non-resonant aluminium chamber, multiple chamber low compression
design, machined aluminum faceplate and stainless steel phase plug
Mid frequency driver 180mm (7”) bass/midrange, powerful vented SD-1 motor, sliced paper cone, low loss linear suspension, low compression
aerodynamic aluminium chassis, spike-mounted in cabinet
Low frequency driver 2 pcs 180mm (7”) bass/midrange, powerful vented SD-1 motor, sliced paper cone, low loss linear suspension, low com
pression aerodynamic aluminium chassis, spike-mounted in cabinet
Crossover network Interlinked multi order Non-Resonant Linked Impulse (NRLI) technology by GamuT, electromagnetic and circuit optimized
electrically separated board layout
Cabinet High density fiber board featuring internal skeleton braces and dampened with bitumen.
Realwood veneer with eleven layers of hand polished high-gloss lacquer
Frequency response 27 – 60.000Hz
Sensitivity 90dB @ 2,83V
Nominal impedance 4 ohms nominal, minimum 2,6ohms at 220 Hz
Recommended power 50-300W
Input connections High-quality, gold plated WBT binding posts with 4mm plugs. Bi-wire and bi-amp capability
Cabinet dimensions (HxWxD) 1280 x 200 x 430mm (50.4 x 7.9 x 16.9”)
Weight 44 kg (99,7lbs)
Stands Stainless steel spikes
