GANSHORN Medizin Electronic GmbH Service Manual Ref.No. 03 140 0 046
PowerCube-Ergo-CASE_ENG_rev.02, 23.11.2012 Chapter 5, software, page 2 of 4
Installation
Please use the GANSHORN Installation Assistant for every installation.
Before performing the installation, please ensure
The correct connection of all parts of the system
The correct installation of the operating system of the installation PC
Warm-up-time
After having performed the installation and before performing measurements with the devices, please
ensure
Check of the correct COM-port
Check or entry of the ambient parameters
Volume calibration of the pneumotach “Blendenspirozeptor”
=> Instruction manual Software LF8,
Appendix A, Calibrations and Tests
Gas calibration of the PowerCube-Ergo
=> Instruction Manual PowerCube-Ergo,
Chapter 5, Calibrations and tests, Ergo calibration (O2/CO2)
If necessary: Allocate external devices or check the parameter allocation
If necessary: Perform customized settings (customer data for report header, input of system
specific data into the LF8-system, etc.)
We strongly recommend to perform a system-printout and a security backup of the LF8-
installation folder.
Warm-up-time
After the first successful test measurement, store and print out the test measurement, then input the
system specific data into the LF8-system
Go into the LF8-system (Setup)
Click below at the right on Service
Enter the password “123ge456” and confirm with OK
Please handle this password confidentially for service purpose only!
Select the register card „System“ and enter system-specific data, customer name, PC-
specifications, peripherie, PC, ergometer etc. Under „Remarks“ input installed programs
Click on close to switch back to the general setup settings
Click on Print Setup to print out the most important setup settings (approx. 3-4 pages) and keep
it for service purposes
