Working procedure AA MTK 70_03
Ambit:
Ganshorn Medizin
Electronic GmbH
Technical Support
Working procedure for PowerCube Ergo /SSO Rev E
Revision: Rev01 30.11.2012
Page 4 von 7
Analog-Modul 1.3
R8 O-PF1
R23 G-PF1
R132 G-O2
R131 O-O2
R26 O-CO
2
K7 PF1 sensor
K17 Amb. Press
Controller-Modul 1.2; 1.3
