GANSHORN PowerCube-Ergo - Page 75

Checklist PP MTK 70_03
Ambit:
Ganshorn Medizin
Electronic GmbH
Technical Support
Checklist for PowerCube Ergo /SSO Rev E
Index: Rev01 30.11.2012
page 2 of 4
6. Visual checks
n..a.
n.OK
OK
Tubes and connectors (not bent, connected tightly, not damaged)
Gas drying tube (not bent, connected tightly, not damaged)
Pneumotach “Blendenspirozeptor” is clean, not damaged
7. Software settings
n..a.
n.OK
OK
Enter actual ambient conditions
Check and adjust actual altitude
m
Cal. gas values entered correctly (Ergo Gas Calibration)
8. Electronic
n..a.
n.OK
OK
Check switching channels
Flow; Offset (2048 Digit), tolerance (± 50 Digit)
Digit
Flow; Gain at 6,25 mbar ( 1000 Digit), tolerance (±20 Digit)
Digit
PwC-Ergo:
Ergo suction flow; measured at mask (0,5-0,7 l/min)
l/min
Ergo pressure reducer; outlet flow (1,2 l/min) (min. 0,1 l/min more than PowerCube suction flow)
l/min
O
2
-Zelle T10/T90 rising time (<200 ms)
ms
O
2
-Zelle T10/T90 drop-out time (<200 ms)
ms
O
2
; Offset with running suction pumps, (2625 Digit), tolerance (±20 Digit)
Digit
O
2
; Gain (Calibration gas Ergo) with running pump ( -625 Digit), tolerance (±50 Digit)
Digit
CO
2
; Offset with running suction pump (1048 Digit), tolerance (±20 Digit)
Digit
CO
2
; Gain (Calibration gas Ergo) with running pump ( 1000 Digit), tolerance (±50 Digit)
Digit
9. System calibration
n..a.
n.OK
O.K
Volume Calibration: Standard Sensor; Diff. in/ex (±70 Digit)
in
ex
Standard Sensor not dependent from different flows
Ergo Gas Calibration
Ergo Gas Calibration
O
2
-
Factor
O
2
-
Offset
CO
2
-
Factor
CO
2
-
Offset
11. Self test
n..a.
n.OK
OK
Patient measurement o.k?
