GANSHORN PowerCube-Ergo - System Identification Elements

GANSHORN Medizin Electronic GmbH Service Manual Ref.No. 03 140 0 046
PowerCube-Ergo-CASE_ENG_rev.02, 23.11.2012 Preface, page 8 of 8
Cross Reference to Possible LF8 Settings
(LF8 screen “system”, see related “Operating instruction manual LF8 – software for pulmonary
function testing”!)
Possible customizing in the LF8-settings is written as follows:
Setup/register-card/register card line number (e.g. setup/general/64)
Keys and Buttons
Framed text indicates keys displayed on the user interface of the software, e.g. Start = software button
labelled with “Start”
Square brackets indicate keyboard keys, e.g. <Alt> = keyboard key labelled with “Alt”
Equipment Identification
Every GANSHORN device has a unique serial number for identification.
The serial number “SN” appears on the device label.
Equipment Symbols
For equipment symbols and their meaning please refer to
=> Instruction Manual PowerCube-Ergo, Preface!
Acronyms
ADC analog to digital converter
ATS American Thoracic Society
cm centimeter
CMOS complementary metal oxide semiconductors
CO2 carbon dioxide
CPU processor unit
ERS European Respiratory Society
HDD hard disc drive
hPa hectopascal
MCU micro controller unit
m meter
ml millilitre
ms millisecond
kg kilogram
l litre
O2 oxygen
OS operating system
PC personal computer
Press. pressure
PwC PowerCube
RAM main storage
s second
Trans. transducer
