Gantner GAT NET.Lock 7000 Manual

Functional description
The electronic locks GAT NET.Lock 7000 are connected to slave control-
lers GAT NET.Controller S 7000. Up to 24 locks can be connected to one
slave controller. Each slave controller in a system is further connected via
serial RS 485 interface to a master controller GAT NET.Controller M 7000.
To use a locker, the user presses the locker door shut and holds his data
carrier up to the reader centre of the GAT NET.Lock 7000. The lock reads
the data carrier information and sends the information to the slave con-
troller. Depending on the operation type (Online/Offline) the user data
are checked by the controller autonomously or by a PC software on the
server. The controller or server response will then signal the lock to lock
or unlock the locker door. The locking status of the door is signalled by
the lock‘s status LED.
Highlights
•Upto24GATNET.Lock7000perGATNET.ControllerS7000
•Differentoperationmodespossible
•Reliabledatatransmissionbetweenthereaderanddatacarrier
•Forleftandrightdoorsandvarioustypesoflockerdoors
•Self-adjustmentoftheRFIDfield
•LEDstatusdisplay(multi-colour)
•Motordrivenlocking/unlockingforhighestreliability
•DifferentboltsetswithintegratedRFIDbooster
•Easyandsecureboltmounting
•Frontplateformetallicdoors(forlabellingwithlockernumberandlogo
etc.), individual designs possible
GAT NET.Lock 7000
Electronic Locker Locks
Application
The GAT NET.Lock 7000 is the ideal solution for the convenient electronic
locking of wardrobe lockers in fitness clubs, baths, golf resorts, and other
individual company applications. The identification at the GAT NET.Lock
7000iscarriedoutviacontactlessRFIDdatacarriers(RadioFrequency
Identification).
The GAT NET.Lock 7000 is suitable for different locker door materials
(wood, HPL, fully synthetic materials, glass or even metal doors when
using the booster unit) and is useable for doors that open to the left or
right. The various operating modes enable the flexible use of these locks.
Slave controllers GAT NET.Controller S 7000 are used for communication
and control of the GAT NET.Lock 7000. They are available for several
RFIDtechnologies(LEGIC
®
andMIFARE
TM
+ISO15693).
Description PartNo.
GAT NET.Lock 7000
ElectronicRFIDlockerlock
368534
1
www.gantner.com
Order information
Description PartNo.
GAT NET.Controller M 7000
Master controller for the slave controllers GAT NET.
Controller S 7000
253224
GAT NET.Controller S 7000 B
Slave control unit for the electronic locker locks GAT NET.
Lock7000,withintegratedLEGIC
®
reader.
253325
GAT NET.Controller S 7000 F/ISO
Slave control unit for the electronic locker locks GAT NET.
Lock7000,withintegratedMIFARE
TM
/ISO15693reader.
253426
GAT NET.Lock Tool 7000
Center punch gage for bolt mounting
533831
GAT NET.Lock Connector
Connector for connection cables
442123
GAT NET.Lock Cable 4m
Cable for connection of the GAT NET.Lock 7000, length 4 m,
4-pin plug on both sides
321826
GAT NET.Lock Label GEA right
GAT NET.Lock Label GEA NUM right
Self-adhesive door label in GANTNER design, for right-
hinged doors, without/with locker number
679034
679236
GAT NET.Lock Label GEA left
GAT NET.Lock Label GEA NUM left
Self-adhesive door label in GANTNER design, for left-
hinged doors, without/with locker number
370022
679135
Accessories
Accessories
Valid as from September 27
th
2013 • Technical data subject to modifications without notice!
DB_GAT-NET-Lock7000--EN_20.indd • Art.Nr.: 573734
GAT NET.Lock 7000
GAT NET.Lock BoltSet 7100
PRELIMINARY
Description PartNo.
GAT NET.Lock Basic Set B
GAT NET.Lock Basic Set F
GAT NET.Lock Basic Set ISO
The sets include master cards
369131
369232
369333
GAT NET.Lock BoltSet 7100
Door shackle carrier and booster for non-metallic doors
369535
GAT NET.Lock BoltSet 7200
Door shackle carrier and booster for metallic doors
532123
