MINI CULTIVATOR & DETHATCHER
INSTRUCTIONS
Y4007
THANK YOU FOR PURCHASING YOUR GARDEN TRAX GARDEN TOOL! IT IS
IMPORTANT THAT YOU READ ALL ASSEMBLY, USAGE AND SAFETY INSTRUCTIONS!
PLEASE TAKE TIME TO READ THIS MANUAL AND FOLLOW ALL INSTRUCTIONS TO
ENHANCE YOUR GARDENING EXPERIENCE! THEN PLEASE REGISTER YOUR
PURCHASE AT
WWW.THUNDERBAYPRODUCTS.COM OR BY FILLING OUT AND
IN YOUR WARRANTY CARD.
MAILING
