4. OPERATION
DANGER! Risk of injury!
Injury when the product starts accidentally.
v Disconnect the product from the mains before
you fill the container.
Watering programs [ Fig. O1 ]:
The watering programs can be set by the rotary switch
q
on the watering control. The watering duration is repeated
at the set watering frequency.
Note:
Art. 1407: A drip head dropper has a flow rate of
approx. 2 litres per hour.
Art. 13158: Each outlet of a drip tube has a flow rate
of approx. 1.6 litres per hour.
To connect the drip heads to the supply pipes
[ Fig. I3 ]:
CAUTION!
The first drip head should be placed directly
above the water surface in the container (see
Fig. O2 / O3). This serves to ventilate the system
and prevents any after-running of the water after
the system has been switched off, especially in the
case of drip heads located below the water level.
1. Cut off the supply pipe
3
vertically at the installation
point of the drip head
5
.
2. Slide the supply pipe
3
fully onto the connection of
the drip head
5
.
3. Slide the other end of the supply pipe
3
fully on the
other connection of the drip head
5
.
4. Repeat steps 1 to 3 until all drip heads
5
are
connected.
5. Slide the end cap
9
onto the free connection of the last
drip head
5
.
To assemble the pipe pegs [ Fig. O2 ]:
We recommend the assembly of 3 pipe pegs per 1 m long
flower box.
1. Insert the tube holders
4
in the desired positions in the
soil of the flower box.
2. Clamp the supply tube
3
into the pipe pegs
4
.
Program table
Rotary switch
position
Watering frequency and Watering duration Litres per day and drip head /
outlet approx.
OFF No watering Art. 1407 Art. 13158
One-time watering for 3 minutes 0.1 litres 0.07 litres
4 h 6 min Every 4 hours for 6 minutes 1.2 litres 0.9 litres
6 h 6 min Every 6 hours for 6 minutes 0.8 litres 0.6 litres
8 h 1 min Every 8 hours for 1 minute 0.1 litres 0.07 litres
8 h 3 min Every 8 hours for 3 minutes 0.3 litres 0.22 litres
8 h 6 min Every 8 hours for 6 minutes 0.6 litres 0.45 litres
12 h 1 min Every 12 hours for 1 minute 0.07 litres 0.05 litres
12 h 3 min Every 12 hours for 3 minutes 0.2 litres 0.15 litres
12 h 6 min Every 12 hours for 6 minutes 0.4 litres 0.3 litres
24 h 1 min Every day for 1 minute 0.03 litres 0.02 litres
24 h 3 min Every day for 3 minutes 0.1 litres 0.07 litres
24 h 6 min Every day for 6 minutes 0.2 litres 0.15 litres
48 h 3 min Every 2nd day for 3 minutes 0.05 litres 0.04 litres
48 h 6 min Every 2nd day for 6 minutes 0.1 litres 0.07 litres
72 h 6 min Every 3rd day for 6 minutes 0.07 litres 0.05 litres
To start the watering [ Fig. O1 / O2 / O3 ]:
CAUTION!
Damage to the pump if it runs dry.
v Make sure that the container is always suffi-
ciently filled with water.
1. Fill the container with the previously calculated amount
of water (make sure that the container in a secure
position).
2. Place the pump in the container filled with water
(make sure that the pump is level with the bottom of
the container).
3. Turn the rotary switch
q
to the OFF position.
EN
12
