22
GB
Fault Possible Cause Remedy
LCD display shows The power supply is over- v Only so many valves may be
ERROR
no
AC
loaded because valves from opened at the same time that
(the programs are retained) other manufacturers have the total power consumption
been used. does not exceed 900 mA.
A
In the event of other faults please contact GARDENA Service.
Repairs should only be carried out by GARDENA service centres or dealers
authorised by GARDENA.
7. Putting Out of Operation
The watering controller is frost-proof down to –20°C.
No measures are required when frost commences.
v Check battery status display before the power supply unit is
disconnected.
Only dispose of batteries when they are flat.
v Return flat batteries to the place you bought them
or
dispose of them properly at your local recycling/disposal centre.
The product must not be added to normal household waste. It
must be disposed of properly.
8. Technical Data
Power supply from power supply unit: 24 V (AC) 900 mA (sufficient for
6 GARDENA Watering Valves Art.1278)
Power supply for memory in case of
mains power failure: Alkaline battery 9 V IEC 6LR61
Life of the battery: At least 1 year (to retain data if there is
a mains failure)
Operating temperature range: From 0°Cto+60°C
Temperature range for storage: –20°C to +70°C
Air humidity: 20 % to 95 % relative humidity
Soil moisture/rain sensor connection: GARDENA-specific
Program saved when replacing battery: Yes (if power supply unit connected)
Number of channels: 4 channels and one master channel,
with max. 4 expansion modules Art.1277
enabling expansion to 12 channels and
one master channel.
Number of program-controlled
watering cycles per channel: Up to 4
Watering duration per program: 1 minute to 4 h 59 min. (100 % Run-Time)
2 minutes to 9 h 58 min. (200 % Run-Time)
Wintering:
Important:
Disposal:
(in accordance with
RL2002 /96 / EC)
