123456CCCC
123456CCCC
24 VAC
POWER
SUPPLY
24 VAC
VALVES
S/N: 00000000
TOP
RESET 5s
MASTER
123456CCM
1. Connect both cables to the cable terminals 24 V (AC) of the Irrigation
Control (polarity does not have to be considered).
2. Plug the power supply unit into an socket.
17
EN
