1. SAFETY
Important!
Read the operator’s manual
carefully before use and keep
for future reference.
Symbols on the product:
Read operator’s manual.
Electrical safety
DANGER! Cardiac arrest!
This product makes an electro-
magnetic field while it operates.
This field may under some con-
ditions interfere with active or
passive medical implants.
To decrease the risk of condi-
tions that can possibly injure or
kill, we recommend persons
with medical implants to speak
with their physician and the
medical implant manufacturer
before you operate the product.
DANGER!
Electric shock!
Risk of injury due to electric
shock.
The product must be supplied
through a residual current device
(RCD) having a rated residual
operating current not exceeding
30 mA.
The product must only be operated
with the 24 V (AC) power supply unit
provided. Do not use an adapter.
Protect the 24 V (AC) power supply
unit from moisture and direct sunlight
when connected.
Install the irrigation control in
a weather proof location.
Check the power cord for damage
before use.
The product must be used only for
controlling commercially available
24V (AC) valves. The electric power
consumption per channel must
not exceed 400 mA (a GARDENA
Irrigation Valve Art.1278 requires
150 mA).
Cable cross-section of the
connection cable:
The maximum permissible distance
between the product and the valve
depends on the cross-section of the
connection cable. For a distance of
30m, the cross section is 0.5 mm
2
and 0.75 mm
2
for a distance of
45m. No more than 3 valves must
be in operation at the same time.
The GARDENA Connection Cable
Art. 1280 is 0.5 mm
2
in size and is
15 m long.
Up to 6 valves can be connected
using this cable. The connection
cable can be connected so that it is
watertight using the GARDENA
Cable Clip Art. 1282.
