PARTS LIST
Before starting to assemble, please check that all parts mentioned on the parts list are in the packaging. Unwrap all
packaging materials and place components on top of carton box or on a clean oor to prevent it from scratching. When
assembling, tighten bolts loosely, and after assembly is completed tighten them fully. Avoid over tightening of nuts and
bolts, this will cause damage to the bolts or other components of the product. Keep small parts out of reach of children.
Nº NAME QTY VISUAL Nº NAME QTY VISUAL
1 CHIMNEY 1 X
12 HINGE 4 X
2
SUPPORT
FOR FRONT
SHELF
2 X 13
VENTILATION
FLAP
1 X
3
BOTTOM
SHELF
3 X 14
WOODEN
TABLE
SUPPORT
2 X
4
HOOK
FOR
GREASE CUP
1 X 15
LARGE
CHAMBER
1 X
5
WOOD
SLOT
1 X 16
SMALL
CHAMBER
1 X
6
SHORT
LEG
2 X 17
LID
FOR LARGE
CHAMBER
1 X
7 WHEEL 2 X 18
LID
FOR SMALL
CHAMBER
1 X
8 AXLE 1 X 19
CHARCOAL
GRID
3 X
9
GREASE
CUP
1 X 20
COOKING
GRID
2 X
10 LONG LEG 2 X 21
COOKING
GRID
HANDLE
2 X
11
CONNECTING
PLATE
2 X 22
WOOD
HANDLE
3 X
Nº NAME QTY VISUAL Nº NAME QTY VISUAL
A M6 X 70 6
F M5 X 10 16
B M6 X 45 2 G M6 2
C M6 X 40 10 H M10 2
D M6 X 25 6 I Ø10 6
E M6 X 12 11
1
