Figure 21
Set the front wheel to the same height as the back wheels!
5.6 HANDLE PANEL
5.6.1 for GBD-46R (DYM1676CE-3)
This model is equipped with a storage box. Push the button in the center to open and lock it (fig. 22).
Figure 22
5.6.2 for GBD-46REV (DYM1676SED-3) & GBD-51REV (DYM1678SD-3)
This model is equipped with a starter battery located in the center of the dashboard. It has got a cup & bottle
holder, too.
Figure 23
Please always put a lid on the drinks in the cupholder.
Holes for different mowing
heights. The height in mm
is embossed in the
bracket.
