Single-mode 5843SHRT 5844SHRT
Optical Budget Typical
19 dB 19 dB
Output power Typical
-14.5 dBm peak -14.5 dBm peak
Receiver Sensitivity Typical
-33.5 dBm peak -33.5 dBm peak
(
9/125 Single-Mode) (9/125 Single-Mode)
Wavelength
1300nm
1300nm
Connector Type
ST
ST
Compatible Fiber Type
Single-Mode (9-13µm) Single-Mode (9-13µm)
Configuration (Switches)
DT
E/DCE DTE/DCE
AC/DC Coupled
AC/DC Coupled
Link/Repeat Link/Repeat
Pin 8 Dr
ive Current Pin 8 Drive Current
Pin 6 +5 V (
DSR or CTS pull-up) Pin 6 +5 V (DSR or CTS pull-up)
Diagnos
tic Mode Diagnostic Mode
Data Rate
DC to 250K bps DC to 250K bps
Data Transmission
Asynchronous, simplex Asynchronous, simplex
or
Full Duplex or Full Duplex
Transmission Distance
up to ~30K meters up to ~30K meters
(
9/125 Cable@0.3dB/km) (9/125 Cable@0.3dB/km)
Bit Error Rate
10-E9 Max. 10-E9 Max.
Point to Point Latency
4
µsec Max 4 µsec Max
Repeat Latency
400 nsec Max 400 nsec Max
Electrical Parameters
Inputs
I/O Data Format
EIA RS232; CCITT v24 EIA RS232; CCITT v24
Data Connector
9 pin D-Type Female 9 pin D-Type Female
Input Impedance
>3000Ohms
>3000O
hms
Input Voltage
+/- 30 Volts Max +/- 30 Volts Max
Outputs
Output Impedance
>300 Ohms >300 Ohms
Driver Output
+/- 5 V min into 3000 Ohms +/- 5 V min into 3000 Ohms
Pin 8 Output
0 to 5V 0 to 5V
67 or
207 Ohm Source Impedance
67 or 207 Ohm
Source Impedance
Ambient Temperature
Operating Temperatures
-
40 to +70 C
-
40 to +70 C
Storage Temperature
-
40 to +85 C
-
40 to +85 C
Power Required
4.1 Watts 5.5 Watts
340 m
A @ 12V 50 mA @ 90-250 V (-H)
340 mA @ 18-60 V (-L)
Power Dissipation BTU/H
10.2 BTU 12.3 BTU
Weight
9 Ozs. 17 Ozs.
Dimensions Inches
2.0W X 5.1L X 1.3H 4.1W X 5.1L X 1.3H
Indicators
Power
Pow
er
T
ransmit Fiber Transmit Fiber
T
ransmit Electrical Transmit Electrical
Rec
eive Fiber Receive Fiber
Rec
eive Electrical Receive Electrical
