6.0 Ordering Information:
LINK/REPEATERS
Part Number
Model EIA Std Fiber Type Input Power Rating
5843HRT RS-232/TTL Multi-Mode 12 Vdc
5844HRT-H RS-232/TTL Multi-Mode 90-250 Vdc/ 90-250 Vac
5844HRT-L RS-232/TTL Multi-Mode 24-48 Vdc
5845HRT EIA 422/485 Multi-Mode 12 Vdc
5846HRT-H EIA 422/485 Multi-Mode 90-250 Vdc/ 90-250 Vac
5846HRT-L EIA 422/485 Multi-Mode 24-48 Vdc
5843SHRT RS-232/TTL Single-Mode 12 Vdc
5844SHRT-H RS-232/TTL Single-Mode 90-250 Vdc/ 90-250 Vac
5844SHRT-L RS-232/TTL Single-Mode 24-48 Vdc
5845SHRT EIA 422/485 Single-Mode 12 Vdc
5846SHRT-H EIA 422/485 Single-Mode 90-250 Vdc/ 90-250 Vac
5846SHRT-L EIA 422/485 Single-Mode 24-48 Vdc
ACCESSORIES
Model Description
4310 AC to 12 Vdc Power adapter for Models 5843HRT and 5845
4310S AC to 12 Vdc Power adapter for Models 5843SHRT and 5845S
ACC-CBL1 DB9 Male/Tinned Lead 10Foot Cable/Pigtail
ACC-LCS Link Cantilever Shelf
Bulletin UM5843 User Manual for Models 5843, 5843S, 5844 and 5844S
Bulletin UM5845 User Manual for Models 5845, 5845S, 5846 and 5846S
5753A-XXXX Simplex Multi-Mode Fiber Optic Cable (62.5/125 µm), 100 KPSI.
Suitable for use in cable troughs, conduit, and outdoor applications.
5754A-XXXX Duplex Multi-Mode Fiber Optic Cable (62.5/125 µm), 100 KPSI.
Suitable for use in cable troughs, conduit, and outdoor applications.
5756A-XXXX Breakout Duplex Multi-Mode Fiber Optic Cable (62.5/125 µm), 100
KPSI. Suitable for use in cable troughs, conduit, and outdoor applica-
tions and direct burial, underground burial, lashed and building riser.
Terminations Cable cut to length, Terminated with ST Type Multi-Mode Fiber Optic
Connector and Complete Assembly Tested
XXXX = the length of the fiber optic cable in Meters (note: order only in full
meters and not a fraction thereof) 1 Meter = 3.281 Feet
