5-3
5.2 Mechanical Dimensions of the 5843HRT and 5843SHRT
DYMEC
MODEL 5843 LINK/REPEATER
RS232
SWITCH ACCESS
MADE IN U.S.A.
5.14
2.06
1.25
.17
1.26
REMOVABLE ACCESS PLATE
9 PIN "D" CONNECTOR WITH
# 4-40 STANDOFF HARDWARE
.50
12 VOLTS DC
Only
#6-32 THREAD SST
.34
TYPE "ST"
F.O. CONNECTOR
GND STUD
4.14
4.64
NOTE: DIMENSIONS ARE IN INCHES.
PWR
RO
E
O
R
T
E
T
T
R
