Part # P152 Rev 1 (01/13/10)Page 10
3. Remove the terminal block access cover.
4. Pass the wires though cable entrance hole.
5. Secure the cable connector
6. Terminate the salamander wire at the terminal block
provided (Red to L1, Black to L2 or N, Green to GRN or E).
NOTE: When mounting a salamander over an existing range
in the eld, an independent fussed connection must be
made though the knock out plate provided in the main back
of the salamander.
Assembly of Backguard/High Shelf
The back guard or high shelf will have been shipped
separately. To install, put the backguard/high shelf on the
rear of the range, slipping the uprights into the opening on
each burner box side. Fasten the upright to the burner box
side with four hex fasteners provided.
Code Requirements
The Garland S/SS680 series complies with the standards CSA
C22.2 no.109 – latest edition, the UL197 – latest edition and
the NSF#4 – latest edition. The installation and connection
of this appliance must comply with current codes. In Canada
– The Canadian Electrical Code Part 1 and in the USA – The
National Electrical Code.
The Garland SU680 series complies with the essential
requirements of the Directives 73/23/EEC, 89/336/EEC,
89/392/EEC, 93/68/EEC and the standards, EN60335,
IEC801.2, IEC801.3, IEC801.4, IEC801.5, IEC801.6 and
IEC801.11.
Electrical Supply
Before attempting the electrical connection, the rating plate
should be checked to ensure that the equipment’s electrical
characteristics and supply electrical characteristics agree. On
ranges and salamanders the supply entrance is located at the
rear or alternatively on the main bottom. The supply terminal
block is accessible from the front. The electrical supply must
be adequate for the voltage, phase, and current marked on
the rating plate.
INSTALLATION continued
NOTE: A means of disconnection from the supply having
a contact separation of at least 3 mm in all poles must be
incorporated in the xed wiring.
This equipment is intended to be installed with xed
permanent wiring.
WARNING: This appliance must be grounded.
Single And Three Phase Connection
Unless otherwise noted, all ranges are shipped from the
factory for three phase connection. Salamanders are shipped
from the factory for single phase connection. A wiring
diagram is attached to the rear of each appliance. Visually
check all electrical connections. The range is wired at the
factory as specied on the order. If it is necessary to change
the phasing refer to the wiring diagram.
Commissioning
Ensure all circuit breakers located in the lower compartment
are set to the ON (1) position.
1. Ensure that all controls are in the OFF position and turn
on the main electrical supply.
2. Operate each section of the range or salamander in
accordance with the instructions given in the Use’s
Manual.
3. Check that the product functions correctly and that the
voltage supply to the unit does not drop more than 5%
when all sections are operated simultaneously.
When the operation has been checked, hand the OPERATING
INSTRUCTIONS to the User or purchaser for retention and
instruct them in the ecient and safe operation of the
appliance.
