Pairing the Remote Control
Before you can use this remote control with your trolling motor, you must pair the remote control to the motor.
1 Turn on the trolling motor.
2 On the trolling motor display panel, press three times to enter pairing mode.
on the trolling motor display panel illuminates blue as it searches for a connection.
3 Bring the remote control within 1m (3ft.) of the display panel on the trolling motor.
4 Turn on the remote control.
5 On the remote control, select > Settings > Remote > Pair > Start.
on the trolling motor display panel illuminates green when the connection is successful.
Calibrating the Remote Control
NOTICE
Calibrate the electronic compass outdoors. To improve heading accuracy, do not stand near objects that
influence magnetic fields, such as vehicles, buildings, and overhead power lines.
You must calibrate the compass in the remote control before you can control the motor using gestures. If the
gesture controls are not working properly after calibration, you can repeat this process as often as needed.
1 Select > Settings > Remote > Calibrate.
2 Select Start, and follow the on-screen instructions.
Specifications
Dimensions (W×H×D) 152 x 52 x 32mm (6 x 2 x 1
1
/
4
in.)
Weight 109g (3.8oz.) without batteries
Material Glass-filled nylon
Display type Sunlight-visible, transflective memory-in-pixel (MIP)
Display resolution R240 x 240 pixels
Display size (diameter) 30.2mm (1
3
/
16
in.)
Operating temperature From -15° to 55°C (5° to 131°F)
Storage temperature From -40° to 85°C (-40° to 185°F)
Battery type 2 AA (not included)
Battery life 240 hr., typical use
Radio frequency 2.4GHz @ 10.0dBm nominal
Water rating IEC 60529 IPX7
1
Compass-safe distance 15cm (6in.)
1
Withstands incidental exposure of water up to 1m for up to 30min.
