Specifications
Specification Value
Dimensions when mounted (H×L) 345 mm (13.58 in.) × 610 mm
(24 in.)
Weight 350 g (12.35 oz.)
Operating temperature From -20° to 50°C (-4° to 122°F)
Storage temperature From 0° to 35°C (32° to 95°F)
Water resistance rating (wind
transducer)
IEC 60529 IPX-6 (protected against
heavy seas)
Water resistance rating (WSI) IEC 60529 IPX-0 (no special
protection)
Power usage (WSI and GND 10) 1.1 W
Typical current draw at 12 VDC
(WSI and GND 10)
95 mA
Wind speed range From 0.9 to 90 knots (From 0.9 to
50 m/s)
5
