USER MANUAL
Technical specifications
Product type All TWIN+ models
Standards / Directives IEC 61851-1 and IEC 61439-7
EMC Classification: 2014/30/EU
Installation method: Ground / Wall
Installation environment: Indoor / Outdoor
Location type: Non-restricted Access
Rated Voltage: 230V / 400V 50Hz
Installation systems: TT, TN and IT* systems
Charging type: Mode 3
Charging method: AC Charging
Protection class: IP44
Mechanical impact resistance: IK10
Temperature range: -25C - +40C
Weight: 14-18kg depending on model
Standard cable length (fixed cable
version):
Standard 4m
Rated current withstand 10kA
Rated short-time withstand current 10kA
Rated conditional short-circuit current
of an assembly
10kA
Short-circuit protective device type Type C
Rated impulse withstand voltage 4kV
Rated insulation voltage 230/400V
Rated current of each circuit 32A
Rated diversity factor RDF=1
Pollution degree: 3
EMC environmental condition A and B
* 1-phase Twin
13
EN
