Magnum 6K32T & 6K32TRC Managed Switch Installation and User Guide 05/07)
5
www GarrettCom com ..
1.2 Ordering Information
Magnum Managed Switch
MODEL DESCRIPTION
Magnum 6K32T 16 10/100 RJ-45 ports managed switch with two optional port modules
(6K32T) which may be configured with a selection of 10/100/1000Mb fiber and copper
connector types, max. 32 ports
Magnum 6K32T-48VDC:Same as 6K32T except power input is –48VDC
Magnum 6K32T-24VDC:Same as 6K32T except power input is 24VDC
Magnum 6K32T-125VDC:Same as 6K32T except power input is 125VDC
Magnum 6K32TRC- Reverse convection cooled(no fans) managed switch, with 16
10/100 RJ-45 ports and two optional port modules which may be configured with a
selection of 10/100/1000Mb fiber and copper connector types,32 ports max.
Magnum 6K32TRC-48VDC:Same as 6K32T except power input is –48VDC
Magnum 6K32TRC-24VDC:Same as 6K32T except power input is 24VDC
Magnum 6K32TRC-125VDC:Same as 6K32T except power input is 125VDC
Configuration Options:
Each Magnum 6K32T & 6K32TRC base unit has two configurable port modules
slot to be configured with any one of the port modules listed below:
Magnum 6K32T & 6K32TRC Port Modules
6KP8-RJ45 TP Module, w/eight 10/100Mbps auto-negotiating RJ-45 ports
6KP4-F10ST “2+2” 10Mb Fiber module, w/ four 10Mb 2km FL ST connectors
6KP4-FXSC “2+2” 100Mb Fiber module, w/ four 100Mb 2km FX SC connectors
6KP4-FXST “2+2” ST Fiber module, w/ s, four 100Mb 2km FX ST connectors
6KP4-FLSTFX “2+2” ST Fiber module, w/ two 100Mb and two 10Mb ports, 2km
6KP6-RJMST “4+2” module, w/four RJ-45 ports and two 2km mm FX SC’s
6KP6-RJMSC “4+2” module, w/four RJ-45 ports and two 2km mm FX ST‘s
6KP6-RJSSC “4+2” module, w/four RJ-45 ports and two 20km Sgl.m FX SC’s
6KP6-RJSSCL “4+2” module, w/four RJ-45 ports and two 40km Sgl.m FX SC’s
6KP8-MTRJ SFF Fiber module, w/eight 100Mb mm FX MT-RJ connectors
6KP8-MLC SFF Fiber module, w/eight 100Mbps mm FX LC connectors
6KP8-SLC SFF Fiber module, w/eight 100Mbps sgl-m FX LC connectors
6KP8-45MT “4+4” module, w/four RJ-45 ports and four 2km mm FX MT-RJ’s
6KP8-45MLC “4+4” module, w/four RJ-45 ports and four 2km mm LC connectors
6KP8-45SLC “4+4” module, w/four RJ-45 ports and four 15km Sm LC connectors
6KP6-MT10ST “4+2” module, w/four MTRJ ports and two 10Mb 2km FL ST’s
6KP6-RJ10ST “4+2” module, w/four RJ-45 ports and two 10Mb 2km FL ST ‘s
6KP8-45-2MT “6+2” module, w/six RJ-45 ports and two 2km mm MTRJ connectors
