ASSEMBLY INSTRUCTIONS
STEP 2
STEP 1
Attach the outer bag to the
middle tube as shown. Make
sure the bag is facing forward
and carefully tighten the collar
by hand. Do not over tighten.
BOX CONTENTS
1. Outer Bag
2. Hypo-Allergenic Bag
3. Hose
4. Power Base
5. Extension Wand
1
2
3
4
5
6
7
8
9
10
11 12 13
6. Middle Tube
7. Handle
8. Handle Tube
9. Power Cord
10. Nuts and Bolts
11. Crevice Tool
12. Upholstery Tool
13. Round Nozzle
Tool
Hook the bag spring clip on
the power base neck to the
slot on the bottom of the bag.
To Next Page
