109
MAINTENANCE
REPLACING THE FILTER BAG
If you notice a loss of suction, the first thing you
should do is check the bag. It is important to replace
the bag whenever it becomes full. Do not try to reuse
a bag. The Garry® vacuum cleaner makes it easy to
check and replace the bag. You can easily check to see
if the bag is full by gently pressing on the front of the
outer bag with your hand.
When the bag needs replacing, follow these simple
steps:
1. First, unzip the outer bag. Gently press on the bag
release tab with one hand and carefully pull the
bag away from the vacuum bag plate.
See Figure 4.
2. As soon as you get the bag off of the plate, pull
on the bag sealing tab to seal the bag before you
remove it from the outer bag. See Figure 5.
3. Lift the bag up and out of the outer bag and
dispose of it.
4. Before you install the new bag, quickly inspect the
vacuum plate to make sure there are no blockages
or other obstructions that might inhibit air flow.
5. Next, slide the new bag into the slots under
the plate and pivot the bag up and around the
vacuum plate. This should be a snug fit. Gently
press the bag past the release tab until it clicks
into place. See Figure 6.
6. Inspect the bag to make sure it is completely
inside the outer back and zip the outer back all
the way closed. You are now ready to continue
using your Garry® vacuum cleaner!
NOTE: The Garry® inner vacuum bag (the bag that
captures the dirt) is not reusable. When it is full,
please dispose of it and replace it.
Figure 4
Figure 6
Figure 5
Sealing tab
INSTRUCTIONS FOR USE
CLEANING CARPETS AND FLOORS
Unwind enough cord for the area you wish to clean
with your Garry® vacuum cleaner. NOTE: You can
quickly remove the entire cord length by simply
twisting the upper cable hook 1/2 turn and removing
the entire cord. See Figure 1.
Plug the cord into an approved power outlet and turn
on your Garry® vacuum cleaner by moving the power
switch on the handle to the “ON” position. You are
now ready to clean your carpets and other flooring
surfaces in your home.
IMPORTANT: Remember to always clear the floor of
metallic objects, and large or sharp objects before you
start to vacuum.
NOTE: If you hear a loud noise from your vacuum such
as blockage by a large object or the roller freezes up,
immediately turn off the vacuum, unplug it, and clear
the roller and power base of any obstructions.
USING ATTACHMENTS
To install your attachments, simply remove the hose
end from the retainer cup and gently press on the
desired attachment. See Figure 2.
IMPORTANT NOTE: You must turn the hose diverter
valve 90 degrees in the counter-clockwise direction in
order to have suction come through the hose.
See Figure 3.
Use the crevice tool for cleaning in narrow or often
difficult to reach areas such as between couch
cushions or along the baseboard where the wall meets
the floor. Use the upholstery tool on your furniture
and other sensitive fabrics to gently lift dust, pet
hair and other debris. The dusting tool is perfect for
dusting mantels, blinds and ceiling fan blades. Also
included with your Garry® vacuum cleaner is an
extension wand, which allows you to extend the reach
of your vacuum to clean high areas and corners safely
and thoroughly.
Figure 1
Figure 2
Figure 3
ToolsFloor
