The DIP Level function on the GFM436 allows two DIP level readings - DIP1 and DIP2 - to be entered and
stored for each location ID.
To change the DIP Level, select the field and press OK. Then use the Left and Right Key to highlight the
digit to be changed and use the Up and Down Keys to increment or decrement that number. To move to
the next digit use the arrow key.
Once you have finished entering the DIP reading press the OK Key to deselect that DIP level. The DIP
level will be saved on exiting the display but switching the instrument off without exiting the display
may cause entered data to be lost.
Pressing the Left Key will navigate to the Velocity Display and pressing the Right Key will navigate to the
Summary Display.
Pressing the Left Soft Key, labelled “Store” will bring up the Store Menu Window.
Pressing the Middle Soft Key, labelled “Menu”, will bring up the Data Storage Menu Window.
Pressing the Right Soft Key (Reset), will reset both DIP readings to 0.00m.
The DIP level will be saved on exiting the display but switching the
instrument off without exiting the display may cause entered data
to be lost.
