Velocity - Flow conversion chart
600.00
500.00
400.00
300.00
200.00
100.00
0.00
0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5
Velocity (ms
-1
)
Velocity - Flow conversion chart
6000.00
5000.00
4000.00
3000.00
2000.00
1000.00
0.00
0 5 10 15 20 25 30 35 40
Velocity (ms
-1
)
GFM400 Series 24 GFM400 Series User Manual
d = 50mm
d = 100mm
d = 150mm
d = 180mm
d = 220mm
d = 250mm
d = 300mm
d = 50mm
d = 100mm
d = 150mm
d = 180mm
d = 220mm
d = 250mm
d = 300mm
