GASLAND PHP40S - Assembly Instructions; Step-by-Step Assembly Guide

www.gaslandchef.com
3330-A Marathon Ct Charleston, SC 29418
support@gaslandchef.com
1 (844) 538-7890
11
3
6
1
3
4
5
1
10
Hardware Used: 4x Bolts and Nuts
(pre-assembled)
Hardware Used: 3x Bolts and Nuts
(pre-assembled to
Brackets)
1. Attach wheels (10) to bottom
plate (1) .
2. Locate the propane cylinder bracket
(11) and attach it on the bottom plate
with 3 bolts and nuts provided with
the bracket.Use the M8x45 screw to
secure the propane cylinder.
19
11
1
Hardware Used: 20x Screws
Hardware Used: 12x Screws
3. Connect and fix the 4 lower support
(6) to the bottom plate(1) and middle
plate (3) with screws (19).
4. Connect 4 upper supports (5) to the
lower supports (6) with screw (19),
then fix the damper with screws (19).
