13. SPECIFICATIONS
Model 4500 5200/5800
External dimension: LXWXH mm 412x260x272 412x265x275
Mass: saw without guide bar and chain, empty tanks kg 4.8 4.9
Volume:
Fuel tank mL 520
Tank for chain lubrication oil mL 260
Fuel (Mixture ratio) 25:1;2-cycle engine oil
Oil (Chain oil) Special chain oil or motor oil
Usable cutting length of guide bar: mm/inch 350/14,400/16,450/18,500/20
Chain:
Specified pitch mm/inch 8.25/0.325 9.53/0.375
Specified Gauge (thickness of drive links) mm/inch 1.47/0.058 1.6/0.063
Type of chain Oregon 21BP
/Carlton K2L
Oregon 75LG
/Carlton A3L
Type of guide bar Sprocket nose
Lubrication Adjustable automatic oil pump
Sprocket: Specified number of teeth 7
Maximum chain speed m/s 20.8
23.6
Engine:
Type Air cooled 2-cycle single cylinder
Carburetor Diaphragm type Walbro WT664
Magneto Flywheel magneto, CDI HX100
Starter Recoil starter
Maximum speed with cutting attachment r/min 11000
Speed at idling r/min 3000+200
Engine displacement: mL(cm3) 45.6 50.2
Fuel consumption: at maximum engine power g/kw.h 520 530
Sound pressure level: (ISO7182) LpAav db(A) 102 104
Guaranteed sound power level:
(ISO9207) LwAav
dB(A) 112 114
Chain brake: (ISO6535) Mean braking time at racing
speed
s 0.09 0.10
Vibration: (ISO7505) ms/s2 10.2 10.8
Other devices: Front hand guard, rear hand guard, throttles
trigger lockout, chain catcher, and chain brake.
Anti-vibration device, spiked bumper
Specifications, descriptions and illustrative material
in this literature are as accurate as known at the
time of publication, but are subject to change
without notice.
Illustration may include optional equipment and
accessories, and may not include all standard
equipment.
