3. Tillbehör
Art. Nr. Beskrivning
56-326-0 Handbrake kit/2 handles
56-326-1 Handbrake kit, one-handed brake
56-327 Frame elevation kit 70 mm
56-330 Gas strut kit 150N incl. attachment/lever
56-368 Gas strut 150N (gas strut only)
56-381 Gas strut kit 200N incl. attachment/lever
56-331 Stirrup
56-332 Linak - Electric motor kit incl. remote control, battery shelf
(MANUAL, GAS only)
56-333 Footplate, Bure Standard (plate)
56-333-1 Platform short
56-383 Platform long
56-334 Drip holder
56-335 Attachment for drip holder
56-336 Oxygen holder
56-337 Side support, adjustable
56-338 Drip rod complete with attachment
56-389 Soft basket with attachment, Bure Standard/S
4. Other instructions – Linak
Control box wiring
1. Battery terminal socket
2. Plug socket
(NOTE: Plugs must always be connected to the control box for IP classication to be valid.)
3. Remote control socket
4. Socket for the raise/lower actuator
NOTE: Make sure that the plus are connected to the correct sockets otherwise the actuators may be damaged
1
2
3
4
