Differentiating CartManager XD model types by electronic board.
By opening up the hood and removing the electronic board cover you can determine which model of CartManager you are
working with.
Model
Part Description
XDW
Uses Controller P/N: E500126-215
XD+
Uses Controller P/N: E500126-210
XDWi
Uses Controller P/N: E500216-13 Note: This electronic board does not have a contactor!
XD
Note: XD units were built with two different model controllers.
1. The XD had Controller P/N: E500126-03 which is DISCONTINUED! It is Replaced by
Controller P/N: E500126-23 (this is a KIT).
2. The newer XD has Controller P/N: E500126-13.
XDW
The CartManager XDW has Controller P/N: E500126-215.
XD+
The CartManager XD+ has Controller P/N: E500126-210.
XDWi
The CartManager XDWi has Controller (i-Drive) P/N:
E500216-13
Note: This electronic board does not have a contactor!
