CRIMPER DETAILS
YOUR CRIMPER DETAILS
SERIAL NUMBER
(LOCATED ON REAR RESERVOIR BASE)
DATE OF PURCHASE
CRIMPER SPECIFICATIONS
DYNAMIC
Nom. Size (Hydraulic Hose Size) 2 inches
Die Set Type 32 series
Crimping Range (inch with Std. Die Set) 1/4 to 2 inches
Crimping Range (inch with Optional Dies) 3/16 to 2½ inches
Radial Swaging Force 4100 kN / 418 tonne
Cycle Speed (Full Stroke-Complete Cycle) 16 seconds
PHYSICAL
Dimensions (Plan inch x inch x Height inch) 27 x 20 x 30
Weight (Without Dies & Oil lbs) 660 lbs / 295 kg
Shipping Space 47,120 cubic inches
Shipping Weight 787 lbs / 358 kg
Crate Size (Plan in x in x Height in). 40 x 31 x 38
ELECTRICAL
Supply (Voltage / Current / Frequency )
230 V
16 A
50 Hz to 60 Hz
Plug Type (North America) NEMA L6 20
Phase Single Phase
Power 4.0 kW / 6.0 HP
HYDRAULIC
Rated Pressure 4300 PSI
Reservoir Capacity 8 US Gallons
Filtration 10 um
MAINTENANCE
Grease Specification Tungsten Disulphide
