SC32 CRIMPER COMPONENT IDENTIFICATION
Dies Not Included
Dies Not Included
Oil Fill & Vent Plug
Caution
The Shipping plug must be
removed and replaced with the
vent plug prior to operating the
equipment
Adjustable Ram
retraction stop
80 Ton Hydraulic
Cylinder
Power On/Off Circuit
Breaker Switch
1HP/2HP 10,000 psi Single
Phase Hydraulic Pump
220 Volt & 110 Volt options are
available
Dial Vernier
Adjuster
Calibration
Adjustment Screw
Manual Pneumatic
Start/Stop switch
Automatic Stop
Switch
PC707
Compression Ring
PC707 Die Set
PC707 Pressure
Plate
Double Angle Top
Compression Ring
Double Angle Die Set
Double Angle
Base Ring
