EXPLODED VIEW PARTS LIST
Ref. No.
1
2
3
4
5
6
7
8
9
10
11
12
13
a
b
Part No.
3091TKL052A
6304FLP034A
3809TKL033A
3043TKK078G
6633TZA015A
6871TPT230A
3313TL8022A
4951TKS093A
6631T11016D
6871TST239C
3846TKK053A
6866TDV004J
6850TD9001G
1SZZTER001H
332-113S
Description
CABINET ASSEMBLY, LG808H G/WAY 3090TKL052 18.1"
LCD(LIQUID CRYSTAL DISPLAY), LM181E06-A4M1 LG PHILPS TFT COLOR SXGA 18.1"
BACK COVER ASSEMBLY, LG808H 3808TKL038 18.1"
TILT SWIVEL ASSEMBLY18INCH . ABS320T(8C793)
INVERTER ASSEMBLY, AMBIT K11I010.00 6 LAMPS FOR LG808H
PWB(PCB) ASSEMBLY,POWER LG808H POWER TOTAL G/WAY
MAIN TOTAL ASSEMBLY LG808H G/WAY CL-29
METAL ASSEMBLY, FRAME LG808H
CONNECTOR ASSEMBLY, 30P H-H 200MM UL20276 18" STD LG808H
PWB(PCB) ASSEMBLY,SUB, LG808H CONTROL TOTAL G/WAY
MARK, PIECE G/WAY LOGO STICKER
CABLE,DVI, UL20276 DT 2000MM BLACK(9930) LG883D DM
CABLE,D-SUB, UL 2990-9C(7.5) DT 1870MM BLACK(9930) , DM
SCREW,DRAWING, D3.0 L10.0 MSWR/BK
SCREW,DRAWING, D3.0 L12.0 MSWR/BK
* Note: Safety mark
